用 Playwright 和 LLM 实现自愈测试自动化

Playwright 是一个用于 Web 自动化和端到端测试的开源框架。如果我们将他和LLM结合，就可以实现“自愈”的自动化测试，这样如果UI有了改动框架不再硬性失败而是在检测到失败之后分析当前的 DOM（Document Object Model），基于规则的策略自动恢复出一个能用的 locator。

自愈遵循一条严格的三阶段 pipeline。

Detection：一个 Playwright 动作抛错，目标元素在 timeout 窗口内没找到。

Diagnosis：框架抓取一份当前页面状态的轻量 DOM 快照，发给 LLM（或交给基于规则的匹配器），识别最接近的元素。

Remediation：生成新 locator，按 confidence 阈值校验，再用它重试原始动作。结果会进入 cache，后续运行不再重复 LLM 调用。

最常见的误解是把自愈只看作 selector 恢复。失败实际上分六类：broken selectors、timing issues、runtime errors、test data problems、visual assertion failures，以及 missing interaction steps。本文实现只聚焦在 selector 恢复，也就是日常测试维护中最高频的那一类。

架构概览

Test action fails │ ▼ waitFor(selector, 3s timeout) ← fast fail, don't block 90s │ timeout ▼ extractDomSnapshot(page) ← trim DOM to 150 interactive elements │ ▼ askGroqForLocator(prompt) ← Llama 3.1-8b-instant via Groq API │ ▼ confidence >= 0.75? YES → saveCache() → retry action with healed locator NO → throw error (explicit fail, no silent pass)

confidence 是这里的关键，当LLM 不够确定的时候，测试就该高声失败而不是悄悄拿错的元素当成功。

这个示例需要三个依赖：

mkdir playwright-self-healing-js cd playwright-self-healing-js npm init -y npm install --save-dev @playwright/test npm install groq-sdk dotenv npx playwright install

在项目根目录建一个 .env 文件，我们用GROQ_API来测试：

GROQ_API_KEY=gsk_xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

Groq 免费层给到 llama-3.1-8b-instant 每天 14,400 次请求、每分钟 30 次请求，对一个测试套件来说是很富裕的。

文件结构如下：

playwright-self-healing-js/ ├── playwright.config.js ├── package.json ├── .env ├── src/ │ ├── self-healer.js ← core: DOM snapshot + Groq + cache │ └── fixtures.js ← Playwright fixture wrapping all actions └── tests/ └── login.spec.js ← 4 test cases

这个项目的核心引擎是src/self-healer.js，他抽取修剪过的 DOM 快照、调 Groq 拿 locator 建议、管基于文件的 cache。

DOM 快照抽取：把一份 500KB 的原始 HTML 丢给 LLM 是浪费。快照只取交互式元素 —— buttons、inputs、links、labels —— 并且只保留与 locator 识别相关的属性：

async function extractDomSnapshot(page) { if (page.isClosed()) { throw new Error('[self-heal] Page already closed — cannot extract snapshot'); } return page.evaluate(() => { const selectors = [ 'button', 'a', 'input', 'select', 'textarea', '[role]', '[data-testid]', 'label', ]; const nodes = document.querySelectorAll(selectors.join(',')); return Array.from(nodes) .slice(0, 150) .map((el) => { const attrs = []; ['id', 'class', 'name', 'type', 'role', 'aria-label', 'data-testid', 'placeholder', 'for'].forEach((a) => { const v = el.getAttribute(a); if (v) attrs.push(`${a}="${v.slice(0, 60)}"`); }); const text = (el.textContent ?? '') .trim().replace(/\s+/g, ' ').slice(0, 80); return `<${el.tagName.toLowerCase()} ${attrs.join(' ')}>${text}</${el.tagName.toLowerCase()}>`; }) .join('\n'); }); }

page.isClosed() 这一行守卫不能省。否则当一个测试在 heal 逻辑跑起来之前就已经 timeout，page.evaluate 会抛 Target page, context or browser has been closed —— 一个把原始问题盖住的错误。

Groq LLM 调用

prompt 给模型下了一条强规则：按严格的优先级顺序返回单个 Playwright locator。0.1 的低 temperature 让输出确定、可复现：

async function askGroqForLocator(originalLocator, domSnapshot, errorMessage) { const prompt = `You are a Playwright automation expert. A UI locator has broken. BROKEN LOCATOR: ${originalLocator} ERROR: ${errorMessage} DOM SNAPSHOT: ${domSnapshot} Return ONE Playwright locator using this priority: 1. page.getByRole('...', { name: '...' }) 2. page.getByTestId('...') 3. page.getByLabel('...') 4. page.getByText('...') 5. page.locator('css') — last resort Return ONLY valid JSON: { "locator": "page.getByRole('button', { name: 'Login' })", "confidence": 0.92, "strategy": "role" }`; const completion = await groq.chat.completions.create({ model: 'llama-3.1-8b-instant', messages: [{ role: 'user', content: prompt }], temperature: 0.1, max_tokens: 200, response_format: { type: 'json_object' }, }); const parsed = JSON.parse(completion.choices[0]?.message?.content ?? '{}'); return { locator: parsed.locator ?? '', confidence: parsed.confidence ?? 0, strategy: parsed.strategy ?? 'unknown', }; }

主函数 healLocator：

async function healLocator(page, originalLocator, error) { const cache = loadCache(); const cached = cache[originalLocator]; // Return cached result if still valid (1 hour TTL) if (cached && (Date.now() - cached.timestamp) < CACHE_TTL_MS) { console.log(`[self-heal] [v] Cache hit: "${originalLocator}" → "${cached.newLocator}"`); return { success: true, newLocator: cached.newLocator, confidence: cached.confidence, strategy: 'cache' }; } const domSnapshot = await extractDomSnapshot(page); const suggestion = await askGroqForLocator(originalLocator, domSnapshot, error.message); // Confidence gate: never silently pass a low-confidence heal if (!suggestion.locator || suggestion.confidence < 0.75) { console.warn(`[self-heal] [!] Low confidence (${suggestion.confidence}). Skipping auto-heal.`); return { success: false, newLocator: null, confidence: suggestion.confidence, strategy: suggestion.strategy }; } // Persist to cache and write audit log cache[originalLocator] = { newLocator: suggestion.locator, confidence: suggestion.confidence, timestamp: Date.now(), }; saveCache(cache); const logLine = `[${new Date().toISOString()}] HEALED: "${originalLocator}" → "${suggestion.locator}" (confidence: ${suggestion.confidence})`; fs.appendFileSync('./healing-report.log', logLine + '\n'); return { success: true, newLocator: suggestion.locator, confidence: suggestion.confidence, strategy: suggestion.strategy }; }

Playwright Fixture：src/fixtures.js

fixture 把每个 Playwright 动作都包在一个 withHeal 助手后面。这里的关键设计是 3 秒的快速 timeout —— 没有它，Playwright 会等满整个 90 秒的 test timeout 才抛错，把预算全部用光，healer 根本来不及跑。

留意 selectOption 的写法：它用了 async (loc) => { await loc.selectOption(value); }，没有走简写 (loc) => loc.selectOption(value)。selectOption 返回的是 Promise<string[]>，没法赋给 Promise，长写法绕开了这个 TypeScript（也是运行时）类型不匹配。

const { test, expect } = require('../src/fixtures'); const BASE_URL = 'https://the-internet.herokuapp.com/login'; // TC-01: Correct locators — healer never triggered test('TC-01 | Login with correct locators (baseline)', async ({ page, healPage }) => { await page.goto(BASE_URL); await healPage.fill('#username', 'tomsmith'); await healPage.fill('#password', 'SuperSecretPassword!'); await healPage.click('button[type="submit"]'); await expect(page.getByText('You logged into a secure area!')).toBeVisible(); }); // TC-02: Broken locators — Groq is called, locators are recovered test('TC-02 | Login with BROKEN locators (self-heal triggered)', async ({ page, healPage }) => { await page.goto(BASE_URL); // Real IDs: #username, #password, button[type="submit"] await healPage.fill('#user-name-input', 'tomsmith'); // ← broken await healPage.fill('#pass-word-field', 'SuperSecretPassword!'); // ← broken await healPage.click('#login-submit-btn'); // ← broken await expect(page.getByText('You logged into a secure area!')).toBeVisible(); }); // TC-03: Same broken locators — cache hit, no Groq call test('TC-03 | Second run — healer reads from cache', async ({ page, healPage }) => { await page.goto(BASE_URL); await healPage.fill('#user-name-input', 'tomsmith'); await healPage.fill('#pass-word-field', 'SuperSecretPassword!'); await healPage.click('#login-submit-btn'); await expect(page.getByText('You logged into a secure area!')).toBeVisible(); }); // TC-04: Negative path — wrong password test('TC-04 | Login fails with wrong password', async ({ page, healPage }) => { await page.goto(BASE_URL); await healPage.fill('#username', 'tomsmith'); await healPage.fill('#password', 'vagrantwashere'); await healPage.click('button[type="submit"]'); const flash = page.locator('#flash'); await expect(flash).toBeVisible(); await expect(flash).toContainText('Your password is invalid!'); });

Playwright 配置

// playwright.config.js module.exports = defineConfig({ testDir: './tests', timeout: 90_000, // 30s is NOT enough: 3 broken locators × Groq latency + assertion retries: 0, // retries are handled by the healer, not Playwright workers: 1, reporter: [ ['list'], ['html', { outputFolder: 'playwright-report', open: 'never', port: 9324 }], ], use: { headless: true, screenshot: 'only-on-failure', video: 'retain-on-failure', }, });

timeout: 90_000 y也是需要的，因为TC-02 会触发三次连续的 Groq 调用，按每次约 300ms 加上网络开销，机器有负载时 30 秒可能不够，90 秒留了足够的余量。

实际遇到的 bug 和修复

TypeScript：'el' is of type 'unknown'

用 TypeScript 版本时，VS Code 在 page.evaluate() 里提示 'el' is of type 'unknown' 和 Cannot find name 'document'。

这是因为tsconfig.json 的 "lib" 数组里没加 "DOM"，TypeScript 不认识浏览器全局变量。page.evaluate 内部的回调虽然运行在浏览器上下文，但 TypeScript 仍会做类型检查，所以 DOM 类型必须在编译器配置里。

修复如下：

{ "compilerOptions": { "lib": ["ES2020", "DOM"] } }

给 .map() 的回调补上 : Element 类型注解：

.map((el: Element) => { ... })

几条实践建议

1、不要静默放过低 confidence 的 heal。0.75 这个阈值不是随手定的。如果低于它，那么LLM 基本就是在猜。让测试失败、把问题端到人面前 review 是最好的方法

2、用基于文件的 cache 时保留 workers: 1。多个 worker 同时往 healing-cache.json 写会把它写坏。要并行的话可以把 cache 换成 SQLite 或 Redis。

3、把 healing-cache.json 加到 .gitignore。cache 条目里的时间戳和 locator 字符串只对当前机器有意义，跨环境没价值，提交 healing 报告日志就够了。

运行测试

# Set your API key (one-time per terminal session) export GROQ_API_KEY=gsk_xxxxxxxxxxxxxxxxxx # Run all tests npm test # Run with visible browser npm run test:headed # Open HTML report (uses port 9324 to avoid EADDRINUSE conflicts) npm run test:report

首次运行的预期输出：

[chromium] › TC-01 | Login with correct locators ✓ 1.2s [chromium] › TC-02 | Login with BROKEN locators [self-heal] 🔍 Locator failed: "#user-name-input". Calling Groq... [self-heal] ✅ Healed → page.getByLabel('Username') (confidence: 0.94) [self-heal] 🔍 Locator failed: "#pass-word-field". Calling Groq... [self-heal] ✅ Healed → page.getByLabel('Password') (confidence: 0.96) [self-heal] 🔍 Locator failed: "#login-submit-btn". Calling Groq... [self-heal] ✅ Healed → page.getByRole('button', { name: 'Login' }) (confidence: 0.91) ✓ 7.4s [chromium] › TC-03 | Second run — cache hit [self-heal] ✅ Cache hit: "#user-name-input" → "page.getByLabel('Username')" [self-heal] ✅ Cache hit: "#pass-word-field" → "page.getByLabel('Password')" [self-heal] ✅ Cache hit: "#login-submit-btn" → "page.getByRole('button', { name: 'Login' })" ✓ 1.8s [chromium] › TC-04 | Login fails with wrong password ✓ 1.1s 4 passed (11.5s)

总结

自愈测试自动化不能替代写得好的 locator，但它解决的是：在 UI 变更慢慢扩散到系统各处的时候，让你的套件保持绿色。并且通过审计日志，以 broken selector 保存遇到的问题，另外可以用Ollama、Gemini等多种 LLM 替代，也会有更好的效果。

https://avoid.overfit.cn/post/f692bc2d2a444d758605b6103c9cdb22

by Tito Irfan Wibisono
